Typical Capacity: 100Ah
Typical Voltage: 3.2V
AC Impedance Resistance(1KHz): ≤0.5mΩ
Standard Charge / discharge current: 0.5C/0.5C
Operating Voltage: 2.5V~3.65V
Description:
EVE LF100MA 3.2V 100Ah LiFePO4 Grade A Battery Cell
Intelligent factory design, high-performance consistency.
Square aluminum shell structure, high precision explosion-proof valve, high safety performance.
Low internal resistance, high discharge rate, and stable discharge platform.
Long cycle life, capacity retention rate over 80% after 4000 cycles at 1C/1C.
Green environmental protection
Typical Capacity: 100Ah
Typical Voltage: 3.2V
AC Impedance Resistance(1KHz): ≤0.5mΩ
Standard Charge / discharge current: 0.5C/0.5C
Operating Voltage: 2.5V~3.65V
Maximum continuous charge/discharge current: 1C/1C
Maximum pulse charge/discharge current(30s): 2C/2C
Recommended scope of SOC: 10%～90%
Charging Temperature: 0℃～55℃
Discharging Temperature: -20℃～55℃
Dimension: 118.5*115.7*97.0mm
Battery weight: 1.92±0.1kg
Encapsulation mode: U-shaped capsule
Applications:
Renewable Energy Storage Systems (Solar Energy Systems)
Electric Vehicles Power Systems
Backup Power Systems
We stand behind our Grade A claims and know you will be more than satisfied with the product you receive. We offer a 30 Day no hassle, MONEYBACK GUARANTEE if you are unsatisfied with your cells for ANY reason. You will be responsible for the return shipping fees unless product is determined to be faulty.
We offer a 1 year warranty on all EVE LiFePO4 battery products. We offer technical support and troubleshooting throughout the duration of the warranty. We can offer greater than a 1 year warranty on the cells but you will need to contact us with your design specs for approval. Large orders of 1,000pcs+ minimum.
Warranties only apply to original owner and are non-transferrable. We will verify your purchase prior to processing any warranty claims or returns.
If it is determined that our product is obviously faulty, we will ship new product to you immediately. We will cover the cost of return shipping. This does not apply to items that have been damaged due to gross negligence, normal wear & tear, improper installation or abuse.
Our warranty does not cover items that have been damaged due to gross negligence, improper installation or abuse. If you are unsure, you should contact us before installing the product.
Please note we have serial numbers for every product we ship so these will be checked and verified before any warranty claim can be started.
Cell chemistry, format, brand and grade depend on the selected product. LiFePO4 prismatic cells are not polymer pouch cells. For raw-cell orders, confirm the manufacturer, model, capacity, dimensions, terminal format, grading and test data before ordering. For replacement battery packs, confirm the compatible device and required cell/PCB configuration. Our real-world batch return rate is kept strictly below 0.3% through our 6-step testing process.
For our standard hot-selling catalog inventory, we can dispatch within 2-5 working days. For large-scale customized OEM or private label orders, production typically takes more days depending on material specifications. We always communicate real-time timeline tracking so you never experience local stockouts.
Our warranty is 12 months from the bill of lading (B/L) dispatch date. No returns to China are required. Send a photo or short video showing the unit SN/QR code and testing anomaly to your account manager. Valid claims are reviewed within 24 business hours. Approved claims may be resolved by replacement in the next shipment or invoice credit; batch defects exceeding 2% qualify for priority replacement dispatch at our cost. Coverage, exclusions and full procedures follow our B2B Support Policy.
Yes, for wholesale buyers looking to scale up, we provide premium OEM services. We can handle custom battery body silk-printing, custom-branded retail boxes with anti-static EVA foam or blister inserts, and warehouse barcode stickers.
Our minimum order quantity is 100 pcs per order. Mixed models are supported. Send your model list and quantities for wholesale pricing; our team will reply within 12 hours. If you need samples for business evaluation before a bulk order, include your company details and expected purchase plan in your inquiry.
Yes. We supply brand-new replacement batteries with professional inspection before shipment.
Each batch is checked for capacity, voltage, internal resistance and overall performance consistency.
Every batch follows quality inspection procedures, including:
This helps maintain stable performance and reduce after-sales issues.
